3D 1080P HDMI Network Extender RJ45 FHD 60M EU plug
Signal transmission: single cat-5e or cat (recommended) cables up to 60 meters instead of HDMI cables are connected between TX and RX Extender.
Audio format support: DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dolby-AC3/DSD.
Support up to 20 meters AWG26 cable length between extender and sources & sink device.
No loss of quality, Support CEC, Installs in minutes.
PRODUCT INFO
RETURNS AND REFUNDS POLICY
COUNTRY OF PURCHASE
Item type:Network Extender
The Single Extender use single Cat-5E or Cat-6(recommended) cables up to 60 meters instead of HDMI cable to transmit high definition signal, for cutting down cost. Long distance transmission of high definition is very difficult because HDMI cable is very expensive and infrequent. The Extender is designed to supply for long distance transmission of high definition signal.
Our devices offer solutions for noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
Signal input: HDMI Signal
Input Video Signal: 0.5-1 volts/p-o
Output Video: HDMI Signal
DTV/HDTV: 480i /576i/ 480P/ 576P/720P/1080i/1080P
CAT-6 Cable: 200FT (60m) for 1080P
Vertical Frequency Range: 50/60Hz
Interlaced Resolutions(50&60Hz): 380i,576i,1080i
Progressive Resolutions(50&60Hz): 480p,576p,720p,1080p
Operating Temperature: 0˚C to 70˚C
Operating Humidity: 10% to 85% RH (no condensation)
Storage Temperature: -10˚C to +80˚C
Storage Humidity: 5% to 90% RH (no condensation)
Power Supply: 5V DC
Power Consumption(MAX): 5W
Power Adapter Standard: US standard
User Manual: English Version
Package Include:
1X Single Transmitter
1X Single Receiver
2X Power Supply
1X User Manual
Note:
The colors deviation might differ due to different monitor settings.
